Medium Excavators 330 - TIER 3

Brand: Cat

Medium Excavator

330 - TIER 3

The Cat® 330 raises the bar for performance and fuel efficiency in this size class. With the industry’s highest level of standard factory technology, a new cab focused on operator comfort and productivity, plus lower fuel and maintenance costs, the 330 will set a new pace for productivity and profit in your operation.

Add To Compare

Increase fuel efficiency up to 20 percent over the 330D2 excavator.
Lift more with up to 15 percent improved lift capacity and increased bucket size over the 330D2 excavator.
Make working on slopes easier with five percent improved swing torque over the 330D2 excavator.
Increase operating efficiency up to 45 percent with standard Cat technologies that lower operator fatigue and your operating costs, including fuel consumption and daily maintenance.
The C7.1 engine can run on biodiesel up to B20 and meets China Nonroad Stage III, UNECE R96 Stage IIIA, and Brazil MAR-1 emission standards, equivalent to U.S. EPA Tier 3/EU Stage IIIA.
The advanced hydraulic system provides the optimum balance of power and efficiency while giving you the control you need for precise digging requirements
Match the excavator to the job with power modes; let Smart mode automatically match engine and hydraulic power to digging conditions.
Advansys™ bucket tips increase penetration and improve cycle times. Tip changes can be done quickly with a simple lug wrench instead of a hammer or special tool, improving safety and uptime.
Auxiliary hydraulic options give you the versatility to use a wide range of Cat attachments.
Don’t let the temperature stop you from working. The excavator has a standard high-ambient temperature capability of 50°C (122°F) with de-rate and cold start capability of –18°C (0°F). An optional –32°C (-25°F) cold start package is available.

Increase fuel efficiency up to 20 percent over the 330D2 excavator.
Lift more with up to 15 percent improved lift capacity and increased bucket size over the 330D2 excavator.
Make working on slopes easier with five percent improved swing torque over the 330D2 excavator.
Increase operating efficiency up to 45 percent with standard Cat technologies that lower operator fatigue and your operating costs, including fuel consumption and daily maintenance.
The C7.1 engine can run on biodiesel up to B20 and meets China Nonroad Stage III, UNECE R96 Stage IIIA, and Brazil MAR-1 emission standards, equivalent to U.S. EPA Tier 3/EU Stage IIIA.
The advanced hydraulic system provides the optimum balance of power and efficiency while giving you the control you need for precise digging requirements
Match the excavator to the job with power modes; let Smart mode automatically match engine and hydraulic power to digging conditions.
Advansys™ bucket tips increase penetration and improve cycle times. Tip changes can be done quickly with a simple lug wrench instead of a hammer or special tool, improving safety and uptime.
Auxiliary hydraulic options give you the versatility to use a wide range of Cat attachments.
Don’t let the temperature stop you from working. The excavator has a standard high-ambient temperature capability of 50°C (122°F) with de-rate and cold start capability of –18°C (0°F). An optional –32°C (-25°F) cold start package is available.

Boost productivity up to 45 percent versus traditional grading with standard Cat Grade with 2D system – includes indicate-only and laser capability.
Dig with guidance to depth, slope, and horizontal distance to grade. You can set up to four different target depth and slope offsets to help save time and money. When the job calls for a different offset, quickly switch through the monitor and get to work.
The 2D system is upgradable to Cat Grade with Advanced 2D or Cat Grade with 3D.
Standard Grade Assist –

Stay on grade – simply and effortlessly – with single-lever digging.
Set your desired bucket angle and let Bucket Assist automatically maintain the angle in sloping, leveling, fine grading, and trenching applications for easy, accurate, and fast jobs.
Keep the tracks on the ground in lifting and hard digging with Boom Assist.
Automatically stop excavator swing at operator-defined set points in truck loading and trenching applications with Swing Assist, which will help you use less effort and consume less fuel.

Standard Cat Payload onboard weighing system –

Cat Payload helps you achieve precise load targets to improve your operating efficiency. Pick up a load of material–with a bucket and thumb combination or grapple and clamshell attachments–and get a real-time weight estimate without swinging.
Take payload data with you. The monitor’s USB port lets you download your results from one shift all the way up to 30 days of work so can manage your progress without needing an internet connection or VisionLink subscription.
Track your daily productivity such as truck target weights and load/cycle counts.
Calibration can be performed in a matter of minutes.
Combine Payload with VisionLink® and remotely manage your production targets.

Upgrade to optional Cat Grade with Advanced 2D –

Create and edit grade designs with ease on a second high-resolution 254 mm (10 in) touchscreen monitor.

Upgrade to optional Cat Grade with 3D –

Want a 3D system to improve your digging results? Caterpillar’s new single antenna global navigation satellite system (GNSS) makes it easy by giving you visual and auditory guidance to grade. Plus you can create and edit designs on the touchscreen monitor while you’re on the job. If your application calls for a dual antenna system, it’s easy to upgrade.
Upgrade to our dual antenna GNSS for maximum grading efficiency. The system lets you create and edit designs on the touchscreen monitor while you’re on the job, or you can have the plan design sent to the excavator to make your work easier. Plus you get added benefits of avoidance zones, cut and fill mapping, lane guidance, and augmented reality along with advanced positioning capability.
Already invested in another brand’s 3D system? No problem. Standard Cat technology like Grade with 2D can readily integrate with that system to give you the precise results you need.
The machine automatically compensates for excavator pitch and roll caused by sloping ground conditions.
Antennas have theft-prevention bolts; a special tool makes them easy for the owner to remove at the end of a shift.

The standard 2D E-fence feature integrated right out of the factory prevents the excavator from moving outside operator-defined set points.
Standard Product Link™ collects data automatically and accurately from your assets – any type and any brand. Information such as location, hours, fuel usage, productivity, idle time, maintenance alerts, diagnostic codes, and machine health can be viewed online through web and mobile applications.
All Cat Grade systems are compatible with radios and base stations from Trimble, Topcon, and Leica. Already invested in a grade infrastructure? You can install grade systems from Trimble, Topcon, and Leica onto the machine.

Two cab options – Comfort and Deluxe – let you choose the level of comfort you need.
Sit in new, wide seats that adjust for operators of all sizes (heated option available).
Get in and out of the cab easier using the tilt-up left console.
Advanced viscous mounts reduce cab vibration up to 50 percent over previous excavator models.
Control the excavator comfortably with easy-to-reach controls all located in front of you.
Stow your gear with plenty of in-cab storage beneath and behind the seat, overhead, and in the consoles. A cup holder, document holder, bottle holder, and coat hook are also provided.
Use the standard radio’s USB ports and Bluetooth® technology to connect personal devices and make hands-free calls.

Start the engine with a push button; use a Bluetooth key fob, or the unique Operator ID function.
Program your power mode and joystick preferences using Operator ID; the excavator will remember what you set each time you go to work.
Trouble cutting through tough material? Auto dig boost gives you an automatic power increase of 8 percent when you need it for better bucket penetration, shorter cycle times, and greater payloads.
Need more lift during your shift? Auto heavy lift gives you 8 percent more power exactly when you need it for as long as you need it.
Make moving the excavator much easier with Cat Stick Steer. Simply push a button and use one hand to travel and turn instead of both hands or feet on levers or pedals.
Make operating easier with the touch of a joystick button. Additional auxiliary relays allow you to power on or turn off a CB radio, beacon light, and even a dust suppression watering system without taking your hands off the joysticks.
Tilt rotator attachments–ours or other brands–work seamlessly with Cat 2D Grade, Assist, Payload, and E-Fence . With no additional hardware required, all you have to do is simply select “Third Party Tiltrotator System Installation” in the monitor, do the calibration, and get to work.
Navigate quickly on the high-resolution monitor.
A second 10 in (254 mm) monitor is available for the advanced grade control..
Protect your hammer tool from overheating and rapid wear. Auto hammer stop warns you after 15 seconds of continuous firing and then automatically shuts it off after 30 seconds – all to extend the tool’s service life.
Find the tool you need – even if it’s hidden beneath overgrowth or debris. The excavator’s onboard Bluetooth reader can search for any work tool equipped with Cat asset tracking devices up to a range of 60 meters (200 feet).
The Cat PL161 Attachment Locator is a Bluetooth device that makes finding your attachments and other gear quick and easy. The excavator’s onboard Bluetooth reader or Cat App on your phone will locate the device automatically.
Save more time and energy with the available work tool recognition feature. A simple shake of the attached tool confirms its identity; it also ensures all the attachment settings are correct so you can get to work quickly and efficiently.
Not sure how a function works or how to maintain the excavator? Always have the operator’s manual at your fingertips in the touchscreen monitor.

Expect up to 25 percent less maintenance cost than the 330D2 (savings calculated over 12,000 machine hours).
Protect your hammer tool from overheating and rapid wear. Auto hammer stop warns you after 15 seconds of continuous firing and then automatically shuts it off after 30 seconds – all to extend the tool’s service life.
Do all daily maintenance at ground level.
Check engine oil level quickly and safely with the new ground-level engine oil dipstick; fill and check engine oil on top of the machine with a conveniently located second dipstick.
Track your excavator’s filter life and maintenance intervals via the in-cab monitor.
Do no required maintenance on the Cat Clean Emissions Module.
Expect the new air intake filter with pre-cleaner to last up to 1,000 hours – a 100 percent increase over the previous filter.
The new hydraulic oil filter provides improved filtration performance, anti-drain valves to keep oil clean when the filter is replaced, and longer life with a 3,000-hour replacement interval – 50 percent longer than previous filter designs.
High-efficiency cooling fans run only when needed; you can program intervals so they automatically reverse to keep cores clean without interrupting your work
S·O·S^SM ports are on ground level, simplifying maintenance and allowing for quick, easy extraction of fluid samples for analysis.
